External Power Cable
Location: The inlet to the power cable is located on the externally facing portion of the power
supply.
Type and number of fastenings: None, direct pressure connection method.
Tools required: None.
Procedure
Step 1: Turn the computer off via the operating system.
Step 2: Disconnect the external power cable from the main desktop assembly.
Reinstallation
Step 1: Connect the external power cable from the rear of the chassis into the power supply
connection point.
Disposal:
Selective Treatment/Special Handling Per Annex VII, Directive 2012/19/EU: Any external
electrical cables must be removed separately and shall be disposed or recovered in
compliance with Directive 2008/98/EC.
