ACE146
Reinstallation
Step 6: To reinstall the Optical Drive, follow the uninstallation steps
backwards.
Step 7: Slide optical drive into the front drive bay in the desired location.
Step 8: Insert (2) screws on the left side of the chassis (when looking from the
front) and (1) screw on the right side of the chassis (when looking from the
front).
Step 9: Reconnect SATA power header to optical drive from PSU and SATA data
cable from optical drive to motherboard. The suggested header for the optical
drive is SATA6G_34.
Disposal:
Selective Treatment/ Special Handling Per Annex VII, Directive 2012/19/EU: The optical
drive contains a printed circuit board of greater than 10 sq. cm and must be removed
from the device and must be disposed of, or recovered, in compliance with the requirements of
Directive 2008/98/EC.
