ACE RC 8310 - Failsafe Function Verification

FAIL SAFE (F/S) FUNCTION SETTING
1. Steering:Neutral
2. Keep brake or keep
trigger at neutral
Pre-settings for F/S
function:
EP Car :
Steering at Neutral /
ESC at Neutral
GP Car :
Steering at Neutral /
Carb. at Iddle
F/S function activates
10
1
2
3
4
5
Status
Boot-up
Green LED flashing
Green LED flashing
Binding OK -
Green LED flashing rapidly
Bind Bee
Bee
PWM abnormal -
Range check -
Tone of buzzer LED (close to Binding SW)
BUZZER LED ( for Cougar PS3i )
1
2
3
4
5
Status
Boot-up
Green LED flashing
Green LED flashing
Binding OK Bee-Bee-Bee
Red / Green LED flashing interactively
Bind Bee
Bee-Bee-Bee
Red LED flashing
PWM abnormal Beep
Range check Beep
Tone of buzzer LED (close to Binding SW)
BUZZER LED ( for Cougar P2 / P3 )
