ACE RC 8310 - Page 5

Transmitter Antenna
Battery Level Indicator
HI/LO Throttle ATV
(Adjustable Travel Volume)
Servo reversing switches
Steering Trim
1
2
3
4
5
Throttle Trim
Steering D/R (Dual Rates)
AUX Ch Button (for P3 only)
External Charging Jack
2.4GHz binding SW
6
7
8
9
10
Steering Wheel
Power Switch
Throttle Trigger
Steering Tension Adjustment
Battery Cover
11
12
13
14
15
