Acer AL1716

16
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
LCD Panel Size 43.2cm(17")
Pixel pitch 0.264mm( H ) × 0.264mm( V )
Brightness 300cd/m
2
(Typical)
Contrast 800:1 (Typical)
Viewable angle 160° (H) 160° (V)
Response time 5 ms
R,G,B Analog Interface Video
Digital (Dual-Input Model)
H-Frequency 30kHz – 80kHz
Input
V-Frequency 55-75Hz
Display Colors 16.2M Colors
Dot Clock 135MHz
Max. Resolution 1280 × 1024 @75Hz
Plug & Play VESA DDC2B
TM
ON Mode ≤ 35W EPA ENERGY STAR
®
OFF Mode
≤ 1W
D-Sub 15pin Input Connector
DVI-D 24pin (Dual-Input Model)
Analog:0.7Vp-p(standard),
75 OHM, Positive
Input Video Signal
Digital signal (Dual-Input Model)
Maximum Screen Size Horizontal : 337.92mm
Vertical : 270.336mm
Power Source 100~264VAC,47~63Hz
Environmental
Considerations
Operating Temp: 0° to 40°C
Storage Temp.: -20° to 60°C
Operating Humidity: 10% to 85%
376(W)×381.6(H)×162.4(D)mm Dimensions
376(W)×375-475(H)×180(D)mm
4.0kgWeight (N. W.)
5.0kg
(AL1716 h /AL1716 r)
(AL1716 )
(AL1716 h /AL1716 r)
(AL1716 )
