- 13 -
AU
Pc interface: 1).Video: RGB analog 0.7V peak to peak
Sync: TTL positive or negative
2) Digital: T.M.D.S.
Signal connector: 15 pin Mini D type, (standard VGA video)
24 pin DVI-D.
3.5 mm stereo audio jack (Audio)
Audio power: 0.5Wrms + 0.5Wrms (300Hz – 10kHz (S.P.L. – 10 dB))
Front control: power on/off with LED select adjustment (+,-)
Interface frequency
Horizontal Frequency 24KHz --80KHz
Vertical Frequency 49Hz ------75Hz
