- 12 -
H-B-P ( us ) 3.810 (120 dots)
3.56(128 dots) 2.200 ( 88 dots) 3.232 (160 dots)
H-Active ( us ) 20.317 (640 dots)
22.22(800 dots)
20.00 ( 800 dots)
16.162 (800 dots)
H-F-P ( us ) 0.508 (16 dots)
0.67(24 dots) 1.000 (40 dots)
0.323 (16 dots)
f v
75Hz (75) 56.25 60Hz (60.316) 75Hz (75.000)
V-Total (ms ) 13.333 (500 lines)
17.78(625 lines)
16.58 (628 lines)
13.333 (625lines)
V-Sync ( ms ) 0.080 (3 lines) 0.06(2 lines) 0.106 (4 lines) 0.064 (3 lines)
V-B-P (ms ) 0.427 (16 lines)
0.63(22 lines) 0.607 (23 lines)
0.448 (21 lines)
V-Active ( ms ) 12.80 (480 lines)
17.07(600 lines)
15.84 (600 lines)
12.80 (600lines)
V-F-P ( ms ) 0.027 ( 1 line )
0.03( 1 line) 0.026 (1 line ) 0.021 (1 line )
SYNC. H/V - / - +/+ + / + + / +
POLARITY
SEP . SYNC Y Y Y Y
MODE NO. 9 10 11 12
RESOLUTION
800 x 600 832 x 624 1024 x 768 1024 x 768
Dot clock(MHz)
50 57.283 65 75
f h
48.077kHz 49.72kHz 48.363kHz 56.48kHz
H-Total ( us ) 20.80 (1040dots)
20.11(1152 dots)
20.677(1344 dots)
17.71(1328 dots)
H-Sync ( us ) 2.400 ( 120 dots)
1.12(64 dots) 2.092(136 dots)
1.81(136 dots)
H-B-P ( us ) 1.280 (64 dots)
3.91(224 dots) 2.462(160 dots)
1.92(144 dots)
H-Active ( us ) 16.00 (800 dots)
14.52( 832 dots )
15.754(1024 dots)
13.65(1024 dots)
H-F-P ( us ) 1.120 (56 dots)
0.56(32 dots ) 0.369(24 dots) 0.32(24 dots)
f v
72Hz (72.188) 74.55Hz 60.004Hz 70.07Hz
V-Total (ms ) 13.85 (666 lines)
13.41(667 lines)
16.666(806 lines)
14.27(806 lines)
V-Sync ( ms ) 0.125 (6 lines) 0.06(3 lines) 0.124(6 lines) 0.11(6 lines)
V-B-P (ms ) 0.478 (23 lines)
0.78(39 lines) 0.600(29 lines)
0.51(29 lines)
V-Active ( ms ) 12.48 (600 lines)
12.55 (624 lines)
15.880(768 lines)
13.60(768 lines)
V-F-P ( ms ) 0.770 ( 37
line )
0.02(1 line) 0.062(3 lines) 0.05(3 lines)
SYNC. H/V + / + +/+ -/- -/-
POLARITY
SEP . SYNC Y Y Y Y
