Acer Aspire 3100 User Manual

Chapter 1 5
Block Diagram
FIR module
2 x PCIE
Power On/Off CKT / LID switch / Power OK CKT
LPC BUS
465 BGA
H_A#(3..31)
ENE Controller
H_D#(0..63)
CB714
USB conn x 2 / New card
HT 16x16 800MHZ
A-Link Express
DC/DC Interface CKT. Power Circuit DC/DC
PCI BUS
AMD Turion/Sempron CPU
ATI-RS485MC
RTC CKT.
549 BGA
AC-LINK
ATI-SB460
AMP & Audio Jack
Slot 0
BT Conn
PATA
5in1 CardReader Slot
Mini PCI Socket
RJ45 CONN
HDD Conn.
Touch Pad CONN.
ENE KB910
Int. KBD
BIOS
SATA HDD Conn.
Conn.
1394
1394 Controller
VT6311S
ALC883 Audio CKT
Realtek RTL8100CL
SMsC LPC47N207
CDROM Conn. MDC Conn.
USB 2.0 USB 2.0
SATA
Clock Generator ICS951462
Thermal Sensor ADM1032ARM
DDRII DDRII-SO-DIMM X2 Dual Channel
Socket S1 638P
CRT & TV-OUT
LCD CONN
One Channel
Mini card RTL8110SCL
CIR/LED
533/667

Acer Aspire 3100 Specifications

General

Brand	Acer
Model	Aspire 3100
Category	Laptop
Language	English
