Base view
# Icon Item Description
1 Battery bay
Houses the computer's battery pack.
2 Battery release latch
Releases the battery for removal.
3 Battery lock
Locks the battery in position.
4 Memory compartment
Houses the computer's main memory.
5Sub woofer
Emits low frequency sound output.
6 Hard disk bay
Houses the computer's hard disk (secured with
screws).
7 Ventilation slots and
cooling fan
Enable the computer to stay cool, even after
prolonged use.
Note: Do not cover or obstruct the opening of
the fan.
