Right view
# Icon Item Description
1 ExpressCard/54 slot Accepts one ExpressCard/54 module.
Note: Push to remove/install the card.
2 USB 2.0 port Connects to USB 2.0 devices
(e.g., USB mouse, USB camera).
3 Optical drive Internal optical drive; accepts CDs or
DVDs.
4 Optical disk access
indicator
Lights up when the optical drive is
active.
5 Optical drive eject
button
Ejects the optical disk from the drive.
6 Emergency eject
hole
Ejects the optical drive tray when the
computer is turned off.
Note: Insert a paper clip to the
emergency eject hole to eject the
optical drive tray when the computer
is off.
7 RF-in port Accepts input signals from digital TV-
tuner devices.
(only for certain models)
8Modem
(RJ-11) port
Connects to a phone line.
9 Kensington lock slot Connects to a Kensington-compatible
computer security lock.
