9
Right view
# Icon Item Description
1 USB 2.0 port Connects to USB 2.0 devices (e.g., USB mouse,
USB camera).
2 USB 2.0 / 3.0* port Connects to USB devices.
* A USB 3.0 port can be distinguished by its
blue connector (for certain models only).
* Supports the USB 3.0 (SuperSpeed USB)
specification; Devices without USB 3.0
certification may not be compatible.
3 Optical drive Internal optical drive; accepts CDs, DVDs, or
Blu-ray Discs (for certain models only).
4 Optical disk access
indicator
Lights up when the optical drive is active.
5 Optical drive eject
button
Ejects the optical disk from the drive.
6 Emergency eject hole Ejects the optical drive tray when the
computer is turned off.
Note: Insert a paper clip to the emergency
eject hole to eject the optical drive tray when
the computer is off.
7 Ethernet (RJ-45) port Connects to an Ethernet 10/100/1000-based
network.
8 DC-in jack Connects to an AC adapter.
