Acer Aspire 8930G - Removing the ODD; Removing the Hinge Cover

Chapter 3 55
17. Remove the card reader dummy.
Removing the ODD
18. Remove the screw fastening the optical disk drive module on the bottom.
19. Use a tool to push the optical disk drive module outwards and remove the ODD module.
Removing the Hinge cover
20. Remove two hinge cover screws.
21. Then detach the Hinge cover from both side.
