3
Program Device Requirements: Audio-0002
1 S/PDIF-out header (1*4)
1 AUX-In header (1*4)
1 front panel audio header (2*5)
Add HD de-pop CKT (the attachment is the reference, please propose
your solution)
S/N ratio: 90 dB at rear output jack
LAN
MAC Controller: Marvell 8071 Gigabit Ethernet controller
Should be worked under 10/100/1000Mbs environment
PHY: Realtek 8211BL Gigabit Ethernet Phy.
USB
Controller Type: RS780M03A1-8KRS2H
Ports Quantity: 12
4 back panel ports
On-board: 3 2*5 headers
4 ports for front daughter board
6 ports for rear I/O
2 ports for internal card reader.
Connector Pin: standard Intel FPIO pin definition
Data transfer rate support:
USB 2.0/1.1
1394
Controller: Jmicron JM831 1394a controller
Connector Quantity: 2
1 rear 6pin IEEE1394 port
1 2x5pin onboard jumper
