Left view
# Icon Item Description
1
DC-in jack Connects to an AC adapter.
2
Ethernet (RJ-45) port
Connects to an Ethernet 10/100/1000-based
networ
k.
3
Ventilation and cooling
fan
Allows the computer to stay cool.
Do not cover or obstruct the openings.
4
HDMI port
Supports high-definition digital video
con
nections.
5
USB port
Connects to USB devices.
If a port is black it is USB 2.0 compatible, if it
is blue it
is also USB 3.0 compatible (see
below).
6
Multi-in-1 card reader
Accepts Secure Digital (SD), MultiMediaCard
(MMC), Memory S
tick PRO (MS PRO), xD-
Picture Card (xD).
Push to remove/install the card. Only one card
can
operate at any given time.
7
Headset/speaker jack
Connects to audio devices (e.g., speakers,
head
phones) or a headset with microphone.
Information on USB 3.0
• Compatible with USB 3.0 and earlier devices.
• For optimal performance, use USB 3.0-certified devices.
• Defined by the USB 3.0 specification (SuperSpeed USB).
