Your Acer notebook tour
8
English
Base view
# Icon Item Description
1
Battery release latch
Releases the battery for removal. Insert a
suit
able tool and slide to release.
2
Memory compartment Houses the computer's main memory.
3 Speakers Deliver stereo audio output.
4 Battery bay Houses the computer's battery pack.
5
Ventilation and cooling
fan
Allows the computer to stay cool.
Do not cover or obstruct the openings.
