1-24 Disassembly Procedures
Top Assembly Removal (Keyboard Removal) 0
Prerequisite:
Ensure that the Speaker module, LED board, and Mainboard have been
disassembled prior removing the top assembly.
The keyboard is included as part of the top assembly and can not be disassembled.
In the event that the keyboard can no longer be used, replace the entire top
assembly.
Figure 1-31. Top Assembly
