Acer Chromebook R753T User Manual

Disassembly Procedures 1-9
Battery Removal 0
Prerequisite:
Base Cover Removal
1. Find the battery pack (A) on the top assembly (Figure 1-6).
2. Detach the tape (B) securing the battery cable to the mainboard connector
(Figure 1-6).
Figure 1-6. Battery Pack Removal
3. Disconnect the battery cable (C) from the mainboard connector (Figure 1-7).
Figure 1-7. Battery Pack Removal
A
B
C

Acer Chromebook R753T Specifications

General

Category	Laptop
Operating System	Chrome OS
RAM	4GB
Battery Life	Up to 12 hours
Color	Black
Display Resolution	1366 x 768 pixels
Wireless	802.11ac
Webcam	HD Webcam
