1-26 Disassembly Procedures
LCD Panel Removal (ZHU/ ZHUA Only) 0
Prerequisite:
LCD Bezel Removal (ZHU/ ZHUA Only)
1. Find the LCD panel (A) in the LCD cover (Figure 1-35).
2. Remove four (4) screws securing the LCD panel in place (Figure 1-35).
Figure 1-35. LCD Panel Removal
3. Carefully turn the LCD panel over so that the display panel is facing down on a flat
surface and the eDP cable connection is exposed (Figure 1-36).
Figure 1-36. LCD Panel Removal
A
WEEE Annex VII Component: LCD Panel
To Next Page
