1-34 Disassembly Procedures
4. Carefully lift the bottom of the keyboard to release it from the top assembly
(Figure 1-49). The upper latches will automatically disengage as you release the
keyboard.
Figure 1-49. Keyboard Removal
Avoid damaging the keyboard FPC when removing the keyboard from the
top assembly.
5. Carefully remove the keyboard from the top assembly (Figure 1-50).
Figure 1-50. Keyboard Removal
