5 Adjust the angle and positioning as necessary.
Note: The appropriate type of screw and washer for each model is
listed in the table below. 3 mm diameter screws are enclosed in the
screw pack.
Mo d el s S cr e w Typ e B Wash e r Ty pe
Diameter (mm) Length (mm) Large Small
P1223/D413D/
EV-X34H/X1223/
D413/EV-X34
48VV
30°
Tightening Screw
Allen Key
Allen Key
Tightening Screw
SCREW SPEC. M4 x 8 mm
210.6 mm
193.6 mm
139.0 mm
