17
Model: Dynamic 2180S 230V 7.5HP
Item
designation
Description
and function
Suppliers
Reference Technical data
Supplier
Name
1
TC1 Transformer
LCP-TBS
JY-159
160VA
0-460V/0-110V
LUNG
GHI
2
QS1
Power on/off
Switch P1-25/V/SVB 600V 10KA 50A MOELLER
3
FU1 Fuse Blocks FSX-303 3P -600V/30A GIKOKA
4
FU2 Fuse Blocks TFB-102 250V/10A TEND
5
FU3 Fuse Blocks TFB-102 250V/10A TEND
6
FU4 Fuse Blocks
7
FU5 Fuse Blocks
8
FU6 Fuse Blocks
9
FU1 Fuse 14*51*3P 500V-50KA/aM40A
10
FU2 Fuse 10*38*2P 30mm/3A
11
FU4 Fuse 10*38*2P 30mm/3A
12
FU5 Fuse 10*38*1P
13
FU6 Fuse 10*38*1P
14
KM1
Magnetic
Contactor CU-27
Coil ac24v/ 230V
7.5HP TECO
15
KM2
Magnetic
Contactor CU-27
Coil ac24v/ 230V
7.5HP TECO
16
KM3
Magnetic
Contactor CU-11-3A1a Coil ac24v/ 230V 5HP TECO
17
KA1
Magnetic
Contactor
CU-11-3A1a Coil ac24v/ 230V 5HP TECO
18
FR1 Overload Relay RHN-80K4 23-32A(26A) TECO
19
FR2 Overload Relay RHN-10K
0.3-0.32A
230V(0.38A) TECO
20
X Terminal Blocks TB30A*6P 600VA /30A GIKOKA
21
X Terminal Blocks TB20A*16P 600VA/ 20A GIKOKA
22
SA1 Selection Switch LSS-251AG 250V 6A 1A (G) RENY
23
SA2 Selection Switch LSS-251AG 250V 6A 1A (G) RENY
24
SB1 Emergency Stop LBK-251BR 250V 6A 1B ( R ) RENY
