Acer Dynamic 1722S - Page 48

48
HEADSTOCK ASSMBLY (Spindle Bore
：
78mm or 3")
97 Plug 3 1120207704 1120207704 1120207704
98 Set screw 3 1120204203 1120204203 1120204203
99 Shifting lever 3 1120204301 1120204301 1120204301
100 Shifting fork 2 112020781 112020781 112020781
101 Shifting fork 1 112020441 112020441 112020441
102 Shifting lever 3 1120204507 1120204507 1120204507
103 Shifting lever 2 1120204605 1120204605 1120204605
103-1 Shifting lever 1 1120204703 1120204703 1120204703
104 Shaft 3 1120204801 1120204801 1120204801
105
Spring
，
D6xd0.8x25L
2
106
Ball steel
，
φ1/4"
2
107 Detent plate 1 1120204909 1120204909 1120204909
108 Detent plate 1 1120205004 1120205004 1120205004
109 Detent plate 1 1120205102 1120205102 1120205102
110 Hub 2 112020521 112020521 112020521
110-1 Hub 1 112020531 112020531 112020531
111
Square key
，
5x5x15L
2
112
Ball steel
，
φ5/16"
3
113
Spring
，
D8xd0.8x25L
3
114 Lever 3 1120207302 1120207302 1120207302
115 Knob 3 1120207400 1120207400 1120207400
116 Shaft 1 1220200501 1220200501 1220200501
117 Shifting lever 1 1120205504 1120205504 1120205504
118 Shifting lever 1 1120208309 1120208309 1120208309
119 Shifting fork 1 3001119-001 3001119-001 3001119-001
119-1 Shifting fork 1 112020561 112020561 112020561
120 Detent plate 1 112020571 112020571 112020571
121 Detent plate 1 112020581 112020581 112020581
122 Knob 1 1120205906 1120205906 1120205906
122-1 Knob 1 1120206001 1120206001 1120206001
123 Shaft 1 1220200403 1220200403 1220200403
124 Washer 5 1120206109 1120206109 1120206109
125 Lever 2 1120207204 1120207204 1120207204
126 Pin 2 1121600709 1121600709 1121600709
127
Set screw
，
M8x1.25x10L
3
