64
BED AND BASE ASSEMBLY
17 Set screw , M8xP1.25x8L 1
18 Spring , 1x6x8L 1
19 Ball-steel , 1/4" 1
20 Lever-turning shaft 4 1122102506 1122102506 1122102506
21 Collar 1 1122103905 1122103905 1122103905
22 Set screw, M8xP1.25x10L 1 91120810 91120810 91120810
23 Supporter-shaft 1 1122102604 1122102604 1122102604
24
Hexagon socket screw ,
M8xP1.25x16L
4
25
Hexagon socket screw ,
M16xP2.0x55L
8
26 Plug 1 1122102702 1122102702 1122102702
27 Bolt-lock 1 1122100208 1122100208 1122100208
28 Cover-motor seat 2 1122100806 1122100806 1122100806
29 Bolt-set machine 6 112210281 112210281 112210281
30 Nut-lock 6 1122102800 1122102800 1122102800
31 Block-leveling 6 1003501809 1003501809 1003501809
32 Bolt-hexa. head W1/4"x25 2
33 Washer , W5/8" 2
34 Seat-coolant pump 1 121010051 121010051 121010051
35 Cover-coolant motor seat 1 1005000403 1005000403 1005000403
36 Nut-lock , W1/4" 2
37 Base (5 feet) 1 1210100209 1210100209 1210100209
(6 feet) 1 1220100202 1220100202 1220100202
(8 feet) 1 1230100205 1230100205 1230100205
(10 feet) 1 1246100208 1246100208 1246100208
