9
ITEM
1 Spindle speed shifting lever 20 Carriage clamping lever
2 Spindle speed H/L shifting lever 21 Foundation leveling screw
3
Spindle speed shifting
selection lever
22 Spindle operation control rod
4 Forward/Reverse Shifting lever 23
4 position automatic feed
stop selection rod
5 Thread/Feed Selection lever 24 Leadscrew
6 Thread/Feed Shifting lever 25 Auto-feed rod
7 10-step feed selection dial 26 Tailstock adjusting gib screw
8
Power source switch
(Main switch)
27 Tailstock body
9 Jog button 28 Tailstock handwheel
10 Coolant supply button 29 Tailstock body Clamping lever
11 Spindle control lever 30 Tailstock spindle locking lever
12 Adjustable trip dog 31 Rack
13 Longitudinal feed hand wheel 32 Compound rest handle
14 Cross slide handle 33 Coolant control ball valve
15 Trip plunger 34 Compound rest
16 Auto feeding engaged lever 35 Four way tool post
17 Foot brake pedal 36 Tool post clamping lever
18 Half nut engagement lever 37 Thread Chasing dial
19 Feed axis selector
