GEAR TRAIN FOR Dynamic 21/25 SERIES, SPINDLE BORE 105MM (4")
GEAR TRAIN FOR Dynamic 25 SERIES, SPINDLE BORE 155MM (6")
NO.
PARTS NO.
DESCRIPTION
Q'TY
REMARK
01
18HA-081000
GEAR 28T, M2.5
1
02
25HA-082000
GEAR 56T, M2.5
1
03
18HA-080000
SAFE PIN BASE
1
04
16B-031000
GEAR 28T, M1.75
1
05
20B-033000
HAVING TWO LAYERS END GEAR 128T, M1.75
HAVING TWO LAYERS END GEAR 120T, M1.75
1
06
20B-038A00
BRACKET
1
07
20B-037000
SHAFT
1
08
20B-036000
SHAFT
1
09
20B-035000
END GEAR 42T, M1.75
1
10
20B-034000
END GEAR 49T, M1.75
1
11
BEARING 6005
2
12
C SNAP RING R47
2
13
C SNAP RING S25
1
14
SPRING WASHER M16
1
15
NUT M16
1
40-2
