TAPER TURNING ATTACHMENT- 21” Series
ITEM
PARTS NO.
DESCRIPTION
Q’TY
NOTE
1
21TA-001
Taper attachment body casting
1
2
21TA-002
Gib-taper turning attachment
1
3
21TA-003
Topslide casting
1
4
21TA-004
Sliding body
1
5
21TA-005
Socket head cap screw
2
6
21TA-006
Rotating sliding plate
1
7
21TA-007
Top cover
1
8
21TA-008
Round head cap screw +
4
9
21TA-009
Locating plate
1
10
21TA-010
Screw with knob
1
11
21TA-011
Socket head cap screw
2
12
21TA-012
Socket head cap screw
1
13
21TA-013
Connecting shaft
1
14
21TA-014
Connecting bracket
1
15
21TA-015
Socket head cap screw
1
16
21TA-016
Socket cap set screw
2
17
21TA-017
Dual side connecting shaft
1
18
21TA-018
Socket cap set screw
2
19
21TA-019
Shaft locating bracket
1
20
21TA-020
Socket head cap screw
2
21
21TA-021
Socket cap set screw
1
22
21TA-022
Hex nut
2
23
21TA-023
Gib screw-taper turning attachment
2
24
21TA-024
Socket head cap screw
4
25
21TA-025
Screw connecting bracket
1
26
21TA-026
Socket head cap screw
1
27
21TA-027
Sleeve
1
28
21TA-028
Connecting plate
1
29
21TA-029
Plate
1
30
21TA-030
Gib
1
For 25” series lathe, please replace 21 with 25 when ordering replacement parts.
