Acer EK271 - SPECIFICATION; LCD Panel; Power Consumption; External Controls

English
SPECIFICATION
LCD Panel
Driving System TFT Color LCD
Size 27”W (69 cm)
Pixel Pitch 0.311mm (H) x 0.311mm (V)
Brightness 250 cd/m
2
(Typical)
Contrast 100000000:1 Max (ACM)
Viewable Angle 178° (H) 178° (V) (CR=10)
Response Time 1ms(VRB)
Panel Type VA
H-Frequency
VGA: 31.469-83.894KHz
HDMI: 31.469-110.000KHz
V-Frequency
VGA: 48-75Hz
HDMI: 48-100Hz
Display Colors 16.7M Colors
Dot Clock
VGA: 174.500MHz
HDMI: 228.800MHz
Maximum Resolution
VGA: 1920x1080 @75Hz
HDMI: 1920x1080 @100Hz
Plug & Play VESA DDCCI/DDC2B
Power Consumption
On Mode 21 W (Typical)
Sleep mode 0.5 W (Typical)
Off Mode 0.3 W (Typical)
Input Connector
D-sub
HDMI (Only HDMI-Input Model) (Optional)
Input Video Signal
Speakers 2W x 2 (Only Audio-Input Model) (Optional)
Maximum Screen Size
Horizontal: 597 mm
Vertical: 336 mm
Power Source INPUT: 100-240 V ~ 50/60 Hz
Environmental Considerations
Operating Temp: 0° to 40°C
Storage Temp: -20° to 60°C
Operating Humidity: 20% to 80%
Dimensions 613.4 (W) x 456.4 (H) x 252.4 (D) mm
Weight (N. W.) 3.50 Kg (net)
Mechanism Specifications
Tilt: -5° to +20°
Swivel: No
Height adjustment: No
Pivot: No
Detachable foot stand: Yes
External Controls
Switch/Buttons Menu/Navi/OK
Functions
Brightness
Contrast
Low Blue Light
Black Boost
ACM
Super Sharpness
Auto Config
H. Position
V. Position
Focus
Clock
Gamma
Color Temp.
Modes
sRGB Mode
Grayscale Mode
6-axis Hue
6-axis Saturate
Volume
Mute
Over Drive
FreeSync
Refresh Rate Num
VRB
Language
OSD Timeout
Transparency
OSD Lock
Input
Auto Source
Wide Mode
DDC/CI
HDMI Black Level
Quick Start Mode
Information
Reset All Settings
Specifications vary depending on model and/or region.
