Machine Maintenance 3-15
Removing the Audio and USB Boards 0
1. Perform the “Removing the Back Cover” procedure described on page 3-7.
2. Use the pull tab to disconnect the audio and USB board connector cable from the
mainboard connector.
Figure 3-20. Audio and USB Board Connector Cable
3. Remove the two screws securing the audio board bracket.
Figure 3-21. Audio Board Bracket Screws
Table 3-2. Screws
Step Screw Quantity Torque Screw Type
Audio Board Bracket
Disassembly
M1.6 x L6 2 0.7+15% to 0.7-15%
Kgf-cm

Acer Iconia A1-810 Specifications

General

Display Size	7.9 inches
Resolution	1024 x 768 pixels
Display Type	IPS LCD
Processor	Mediatek MT8125
CPU	Quad-core 1.2 GHz Cortex-A7
GPU	PowerVR SGX544
RAM	1 GB
Internal Storage	16 GB
Expandable Storage	microSD, up to 32 GB
Rear Camera	5 MP
Front Camera	0.3 MP
Battery Capacity	4960 mAh
Operating System	Android 4.2.2 (Jelly Bean)
Weight	410 g
Wireless	Wi-Fi 802.11 b/g/n
Bluetooth	Bluetooth 4.0
Dimensions	208.7 x 145.7 x 10.5 mm
