Acer Iconia A1-810 User Manual

Machine Maintenance 3-29
Replacing the Rear Camera Module 0
1. Insert the rear camera module into the middle frame.
Figure 3-45. Rear Camera Module
2. Connect the camera cable to the mainboard and then close the connector latch.
Figure 3-46. Camera Cable

Acer Iconia A1-810 Specifications

General

Display Size	7.9 inches
Resolution	1024 x 768 pixels
Display Type	IPS LCD
Processor	Mediatek MT8125
CPU	Quad-core 1.2 GHz Cortex-A7
GPU	PowerVR SGX544
RAM	1 GB
Internal Storage	16 GB
Expandable Storage	microSD, up to 32 GB
Rear Camera	5 MP
Front Camera	0.3 MP
Battery Capacity	4960 mAh
Operating System	Android 4.2.2 (Jelly Bean)
Weight	410 g
Wireless	Wi-Fi 802.11 b/g/n
Bluetooth	Bluetooth 4.0
Dimensions	208.7 x 145.7 x 10.5 mm
