16 - Your Acer notebook tour
Left view
USB 3.2 (AN16-51/AN17-51/AN17-71 ) / USB 2.0 (AN16-41/
AN17-41) information
• USB 3.2 Gen 1 compatible ports are blue.
• USB 2.0 compatible ports are black.
• Compatible with USB 3.2 Gen 1 / USB 2.0 and earlier devices.
• For optimal performance, use USB 3.2 Gen 1-certified / USB 2.0-
certified devices.
• Defined by the USB 3.2 Gen 1 / USB 2.0 specification
(SuperSpeed USB).
# Icon Item Description
1
Ventilation and
cooling fan
Allows the computer to stay cool.
Do not cover or obstruct the
openings.
2
Ethernet (RJ-45)
port
Connects to an Ethernet 10/100/
1000Mbps/2.5Gbps-based
network.
3 USB port Connects to USB devices.
4
MicroSD card
slot
Accepts one Secure Digital
(microSD) card.
Only one card can operate at a time.
5
Headset/
speaker jack
Connects to audio devices (e.g.,
speakers, headphones) or a
headset with microphone.
