5
English
Base view
# Item Description
1 Memory bay Houses the computer's main memory.
2 Battery lock Locks the battery in place.
3 Battery release
latch
Releases the battery for removal.
4 Battery bay Houses the computer's battery pack.
5 Cooling fan Helps keep the computer cool.
Note: Do not cover or obstruct the opening of the fan.
6 Wireless LAN and
hard disk bay
Houses the computer's WLAN and hard disk (secured
with screws).
