8
Left view
# Icon Item Description
1 Kensington lock slot Connects to a Kensington-
compatible computer security lock.
Note: Wrap the computer security
lock cable around an immovable
object such as a table or handle of a
locked drawer. Insert the lock into
the notch and turn the key to
secure the lock. Some keyless
models are also available.
2 Acer EasyPort
connector
Connects to the Acer EasyPort.
3 Ventilation slots Enable the computer to stay cool,
even after prolonged use.
4 Ethernet (RJ-45) port Connects to an Ethernet 10/100/
1000-based network.
5 External display
(VGA) port
Connects to a display device (e.g.,
external monitor, LCD projector).
6 USB 2.0 port Connects to USB 2.0 devices (e.g.,
USB mouse, USB camera).
7
Microphone-in jack
Accepts inputs from external
microphones.
Headphones/speaker/
line-out jack
Connects to audio line-out devices
(e.g., speakers, headphones).
