Assembly Instruction
7
1
2
16 M8x60mm Carriage Bolt x 4
27 M8x19mm Washer x 4
42 M8 Acorn Nut x 4
Turn Locking Knob (5) counterclockwise to loosen then
IMPORTANT: Be sure the Locking Knob is inserted into
the hole of Seat Post, turn clockwise to tighten.
slide Seat Post (3) into Main Frme.
To Next Page
