5
6
Turn Locking Knob (63) counterclockwise to loosen,
pull the knob as you insert Seat Post Slider (64)
IMPORTANT: Turn Locking Knob clockwise to secure
seat before use.
Connect the three wires
48 M8X15mm Hex Head Screw x4
49 M8x18mm Curved Washer x4
Freecall for service 1-800-465-0 www.actionsports.com.au
Assembly Instruction
Freecall for service 07 3272 7010 www.bfe.net.au
9
