aci A/CTE-50 User Manual

AUTOMATION COMPONENTS, INC Version : 1.0
2305 Pleasant View Road Page 3 of 3 I0000141
Middleton, Wisconsin 53562 (888) 967-5224
www.workaci.com

 Current Conversion Formulas
To convert the current sensor output signal to a current reading.
0-10 Volt output to Current reading (0 Volts = 0 Amps and 10 Volts = 250 Amps for A/CTV-250)
Example: 5 Volts current sensor output signal
Total Span = 250 Amps
Multiplier = 10V-0V/Total Span = .04
(5 Volts) / 0.04 = 125 Amps
 WEEE Directive
At the end of their useful life the packaging and product should be disposed of via a suitable recycling centre. Do not dispose of
with household waste. Do not burn.
LISTED
C US
IND.CONT.EQ.
3JHX

aci A/CTE-50 Specifications

General

Brand	aci
Model	A/CTE-50
Category	Accessories
Language	English
