ACM ACM208 User Manual

3
programming mode
To unlock the door for a PIN user
Enter the PIN then press #
To unlock the door for a card user
Present the card
3. Description
The unit is single door multifunction standalone access controller or a Wiegand output
keypad or card reader. It is suitable for mounting either indoor or outdoor in harsh
environments. It is housed in a strong, sturdy and vandal proof Zinc Alloy electroplated
case which is available in either a bright silver or matt silver finish. The electronics are
fully potted so the unit is waterproof and conforms to IP68. This unit supports up to 2000
users in either a Card, 4 digit PIN, or a Card + PIN option. The inbuilt card reader supports
125KHZ EM cards,13.56MHz Mifare cards. The unit has many extra features including
lock output current short circuit protection, Wiegand output , and a backlit keypad. These
features make the unit an ideal choice for door access not only for small shops and
domestic households but also for commercial and industrial applications such as factories,
warehouses, laboratories, banks and prisons.
4. Features
 Waterproof, conforms to IP68
 Strong Zinc Alloy Electroplated anti-vandal case
 Full programming from the keypad
 2000 uses, supports Card, PIN, Card + PIN
 Can be used as a stand alone keypad
 Backlight keys
 Wiegand 26 input for connection to external reader
 Wiegand 26 output for connection to a controller
 Adjustable Door Output time, Alarm time, Door Open time
 Very low power consumption (30mA)
 Fast operating speed, <20ms with 2000 users
 Lock output current short circuit protection
 Easy to install and program
 Built in light dependent resistor (LDR) for anti tamper
 Built in buzzer
 Red, Yellow and Green LEDS display the working status

ACM ACM208 Specifications

General

Brand	ACM
Model	ACM208
Category	IP Access Controllers
Language	English
