58 Channels (Mode 1):
CHANNEL VALUE FUNCTION
1
000-255
PAN
0°

540°
2 000-255 PAN FINE
3
000-255
TILT
0°

450°
4 000-255 TILT FINE
5
000-127
128-189
190-193
194-255
PAN INFINITY
Pan Position
CCW Rotation, Fast to Slow
Stop
CW Rotation, Slow to Fast
6
000-127
128-189
190-193
194-255
TILT INFINITY
Tilt Position
CW Rotation, Fast to Slow
Stop
CCW Rotation, Slow to Fast
7
000-255
PAN/TILT SPEED
Fast to Slow
8
000-255
RED1
0%

100%
9
000-255
GREEN1
0%100%
10
000-255
BLUE1
0%

100%
11
000-255
WHITE1
0%100%
12
000-255
RED2
0%

100%
13
000-255
GREEN2
0%100%
14
000-255
BLUE2
0%

100%
15
000-255
WHITE2
0%100%
16
000-255
RED3
0%

100%
17
000-255
GREEN3
0%

100%
18
000-255
BLUE3
0%

100%
