35+ Channels Mode (Controlled by DMX):
CHANNEL VALUE FUNCTION
1
000-255
PAN
0°

540°
2 000-255 PAN FINE
3
000-255
TILT
0°

450°
4 000-255 TILT FINE
5
000-127
128-189
190-193
194-255
PAN INFINITY
Pan Position
CCW Rotation, Fast to Slow
Stop
CW Rotation, Slow to Fast
6
000-127
128-189
190-193
194-255
TILT INFINITY
Tilt Position
CW Rotation, Fast to Slow
Stop
CCW Rotation, Slow to Fast
7
000-255
PAN/TILT SPEED
Fast to Slow
8
000-255
LED WHITE1
0%

100%
9
000-255
LED WHITE2
0%100%
10
000-255
LED WHITE3
0%

100%
11
000-255
LED WHITE4
0%100%
12
000-255
LED WHITE5
0%

100%
13
000-255
LED WHITE6
0%100%
14
000-255
LED WHITE7
0%

100%
15
000-255
LED WHITE8
0%100%
16
000-255
LED WHITE9
0%

100%
17
000-255
LED WHITE10
0%

100%
18
000-255
LED WHITE11
0%

100%
