70 Channels (Mode 6):
CHANNEL VALUE FUNCTION
1
000-255
PAN
0°

540°
2 000-255 PAN FINE
3
000-255
TILT
0°

450°
4 000-255 TILT FINE
5
000-127
128-189
190-193
194-255
PAN INFINITY
Pan Position
CCW Rotation, Fast to Slow
Stop
CW Rotation, Slow to Fast
6
000-127
128-189
190-193
194-255
TILT INFINITY
Tilt Position
CW Rotation, Fast to Slow
Stop
CCW Rotation, Slow to Fast
7
000-255
PAN/TILT SPEED
Fast to Slow
8
000-255
RED1
0%

100%
9
000-255
GREEN1
0%100%
10
000-255
BLUE1
0%

100%
11
000-255
WHITE1
0%100%
12
000-007
008-015
016-131
132-139
140-181
182-189
190-231
232-239
240-247
248-255
STROBE1
Close
Open
Strobe, Slow to Fast
Open
Fast Close Slow Open
Open
Fast Open Slow Close
Open
Random Strobe
Open
13
000-255
DIMMER1
0%100%
14 000-255 DIMMER FINE1
