3. Main Function
1. Mains input：IEC socket and integrated fuse holder, connect to main power cable.
2. DMX OUT： Transmit DMX signal by 3-Pin XLR female socket.
3. DMX IN： Receive DMX signal by 3-Pin XLR male socket.
4. Remote controller input： Connecting with 1/4” microphone jack to control the
scene for Stand by, Function, and Mode function
selections.
5. Microphone：Receive audio signal for sound activated.
6. Sensitivity：Adjust the sound-input sensitivity.
7. Dip switches：Dip 10 for Master/Slave setting such as Dip 10 ON is MASTER mode
and Dip 10 OFF is SLAVE mode. Dips 1-9 are used to set DMX
address of the unit.
