11
Error Correction: V.42/MNP2,3,4
Other Function: Plug and Play ,ACPI Power
management compliantly .
Host Interface: Plug and Play PCI bus interface.
Transmit Level: -11dBm
Receiver Sensitivity: -32dBm(V.34);-36dBm(all other
protocols)
DTE Speeds: 300-115200bps
Operating Temperature: -0 - + 55 degrees C
Storage Temperature: -50 - + 70 degrees C
Appendix B - Specifications
Installation Restart the computer after plugging in the
modem. When Windows detects the mo-
dem, the message "This wizard will
compiet the installation of:PCI Serial Con-
troller" is displayed.
Click "next" other location",then enter then
path to the drivers, then click "OK".
Windows disp;ays "Windows found the
folloewing updated driver for this
device:Rockwell PCI Modem Enumera-
tor".
Click "Finish" and Windows displays
"Please insert the disk labeled WIN95
Installion Disk, and then click OK."
Click "OK" and enter the path of the drivers
again. Insataiition should then complete
automaticcally.
Uninstalling Click on the "Add/Remove Programs"icon
under START>SETTINGS>CONTROL
PANEL.
Select "Rockwell HCF 56k Modem" under
the INSTALL/UNIINSTALL tab and click
the "ADD/REMOVE" button.
When completed successfully, the INF
files, VXDs, and registry entries caused
by the modem installation are deleted from
the hard disk. The system should be
rebooted at this point if a modem is to be
reinstalled.
