LIMITATIONS
The connection signal can be blocked by carbon and metal. Operation on carbon or, metal boats will
require the Guardian box to be mounted externally.
SOUND AND LIGHT INDICATIONS
OPERATION ACTION/REACTION DURATION
Turning ON
Control switch - Green
2 secondsBox – Low red
Buzzer ON
No OLAS transmitters in range
Control switch – Red
Pulsing 0.5 seconds
ON/OFF
Box – Low red
Buzzer ON
Initial scan for OLAS transmitters within 1 meter
Control switch – Green
Pulsing 1 second ON/OFF for 30
seconds
Box – Low red
Indication of logged OLAS transmitters
Control switch – Green
Pulsing 0.5 seconds ON/OFF, 1 pulse
per transmitter up to max 15
Box – Low red
Buzzer ON
Tracking OLAS transmitters Control switch – Green Continuous
MOB Alert
Control switch - Red
Continuous lights
Pulsing buzzer
Box – High red
Buzzer ON
Tracking paused
Control switch – Green
Pulsing 3 second ON/OFF
Buzzer once every 6 seconds
Box – Low red
Buzzer ON
Scanning and logging transmitters within 1 meter
Control switch – Green
Pulsing 1 second ON/OFF
Box – Low red
Low battery alert for OLAS tag
NOTE: OLAS Float-On does not transmit battery status
Control switch – Red
Pulsing once every
10 seconds
Box – Low red LED
SPECIFICATION
Power/Current 10-32V/13~17mA
Vessel length 50ft
Connected Transmitters up to 15
Weight 110 grams
Size 92 x 90 x 38 mm
LED output 55lm
Buzzer output 85db
