Anatomy of your Beacon (PLB-425)
Anatomy of your Beacon
The PLB-425 includes all the features (A through H)
marked on the PLB-400 diagram on the previous page.
The PLB-400 and PLB-425 are functionally the same
except the PLB-425 also includes a digital screen as
depicted by letter “I” in the diagram to the right.
Throughout the rest of the manual, beacon images
which include a screen represent the PLB-425 and
images without a screen represent the PLB-400.
WARNING: This transmitter is authorized for
use only during situations of grave and
imminent danger. Deliberate misuse may
incur a severe penalty.
A
D
C
B
E
F
G
I
