FIGURE 5
NOTE:
The Numerical Component
designations indicated in this
Illustration are for reference
purposes only for use within
this Instruction Manual.
'5,9($66(0%/<ZLWK237,216
1.
Motor
2.
Gear-reducer
3.
Gearbox
45.
Optical Tachometer (Optional)
80.
Torque Limiter Coupling (Optional)
81.
Magnetic Clutch (Optional)
99.
Magnetic Tachometer (Optional)
NOTE:
Only one Tachometer (45 or 99) is furnished (when a variable speed DC
drive is used).
28
