ACS ALCOLOCK LR - Introduction and System Overview; Important Safety and Usage Precautions; Download Station Description; ACS Components Listing

Introduction
This manual provides instructions for the connection of the ALCOLOCK LR download station.
ATTENTION!
• Thisguideisintendedforauthorizedservicetechniciansonly
• UsewiththeALCOLOCKLRalcoholinterlockonly
• ThisguideisintendedforusewiththeINTERTRACKenterprise(ITE)webapplication
manual
• Ensurethatthepower-supplypowerratingsconformtothelocalsupplyratings
• Donotforceamisalignedconnectorintoplace,asdoingsomaydamagethe
components
Download station – description
• DownloadseventlogfromALCOLOCKLRhandset
• OperateswithITEwebapplication
ACS parts
• ALCOLOCKLRdownloadstation(NorthAmerica):79-008952
• ALCOLOCKLRdownloadstation(Europe):79-008954
• Powersupply:07-000074
• Plugattachment(NorthAmerica):27-000120
• Plugattachment(Europe):27-000121
Connection steps
1. Onthepowersupply:pressandholdthe“PUSH”buttonandslide-outtheclearprotective
cover.
2. Pressandholdthe“PUSH”buttonandslide-intheappropriateplugattachmentforyour
locality.Theattachmentlatchesintoplace.
“PUSH”
