A5MSY-2010 Outline and Dimension
Indoor Unit
Model: A5CCY 10/15/20/25CR
Note: Dimension in mm
Indoor Unit
Model: A5CMY 15/20/25ER
Note: Dimension in mm
MODEL
ABCDEFGH I J KLMNO
A5CCY 10/15CR
31 881 842 802 10 905 72 261 411 351 225 211 232 212,8 114
A5CCY 20CR
31 1041 1002 962 10 1065 72 261 411 351 225 211 232 212,8 114
A5CCY 25CR
31 1176 1137 1097 10 1200 72 261 411 351 225 211 232 212,8 114
