Acson ACK15BW User Manual

1-6
ELECTRICAL WIRING CONNECTION
This is a proposed wiring connection. It may change subject to the chiller unit and must comply with the local and national
code and regulations.
MODEL : CK15BW - CK30BW
3WV3WV
X1 X2 X3
3WV
R
COMPCOMPL/L1
N/L2 N/L2 COMP
S
T
N
CHILLER
FCU 1 FCU 2 FCU 3
200-240V/1 /50Hz
208-230V/1 /60Hz
3WV
Solenoid Valve for 3 way valve
Relay (220-240V, 10A)
X1, X2, X3
L/L1 N/L2 N/L2 L/L1 N/L2 N/L2
MODEL : CK10CW - CK20CW
X1 X2
X3
3WV 3WV 3WV
R
L/L1 N/L2 N/L2COMP
S
T
N
CHILLER
FCU 1
L/L1 N/L2 N/L2COMP
FCU 3
L/L1 N/L2 N/L2COMP
FCU 2
200-240V/1 /50Hz
208-230V/1 /60Hz
3WV
Solenoid Valve for 3 way valve
Relay (220-240V, 10A)
X1, X2, X3
