Engineering & Physical Data AWM-G-2009
General Data - Heat pump (R410A)
MODEL
INDOOR UNIT A5WM 20GR A5WM 25GR
OUTDOOR UNIT A5LC 20CR A5LC 25CR
NOMINAL COOLING CAPACITY- 1Ø / <3Ø>
Btu/h 17850 / <18000> 20350 / <22500>
W 5230 / <5280> 5960 / <6590>
NOMINAL HEATING CAPACITY- 1Ø / <3Ø>
Btu/h 18000 / <18500> 22000 / <23000>
W 5280 / <5420> 6448 / <6740>
NOMINAL TOTAL INPUT POWER (COOLING)- 1Ø / <3Ø> W 1630 / <1663> 1860 / <2195>
NOMINAL TOTAL INPUT POWER (HEATING)- 1Ø / <3Ø> W 1546 / <1630> 1870 / <2106>
NOMINAL RUNNING CURRENT (COOLING)- 1Ø / <3Ø> A 7.2 / <3.2> 8.4 / <4.2>
NOMINAL RUNNING CURRENT (HEATING)- 1Ø / <3Ø> A 6.8 / <3.1> 8.4 / <4.2>
POWER SOURCE- 1Ø / <3Ø> V/Ph/Hz 220-240/ 1/ 50 / <380-415/ 3/ 50> 220-240/ 1/ 50 / <380-415/ 3/ 50>
EER- 1Ø / <3Ø> W/W 3.21 / <3.17> 3.21 / <3.00>
COP- 1Ø / <3Ø> W/W 3.42 / <3.33> 3.45 / <3.20>
REFRIGERANT TYPE R410A R410A
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE
INDOOR UNIT
CONTROL
AIR DISCHARGE
DOUBLE LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
DOUBLE LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
OPERATION LCD REMOTE CONTROL LCD REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 231 / 490 297 / 630
MEDIUM l/s / CFM 193 / 410 231 / 490
LOW l/s / CFM 160 / 340 208 / 440
SOUND PRESSURE LEVEL (H/M/L) dBA 43 / 40 / 35 49 / 44 / 42
UNIT DIMENSION
HEIGHT mm/in 304 / 12.0 304 / 12.0
WIDTH mm/in 1062 / 41.8 1062 / 41.8
DEPTH mm/in 222 / 8.7 222 / 8.7
PACKING DIMENSION
HEIGHT mm/in 378 / 14.9 378 / 14.9
WIDTH mm/in 1130 / 44.5 1130 / 44.5
DEPTH mm/in 292 / 11.5 292 / 11.5
UNIT WEIGHT kg/lb 16 / 35.3 16 / 35.3
CONDENSATE DRAIN SIZE mm/in 20 / 0.8 20 / 0.8
OUTDOOR UNIT
AIR FLOW l/s / CFM 614 / 1300 689 / 1460
SOUND PRESSURE LEVEL dBA 52 52
UNIT DIMENSION
HEIGHT mm/in 654 / 25.7 756 / 29.8
WIDTH mm/in 855 / 33.7 855 / 33.7
DEPTH mm/in 328 / 12.9 328 / 12.9
PACKING DIMENSION
HEIGHT mm/in 710 / 28.0 810 / 31.9
WIDTH mm/in 990 / 39.0 990 / 39.0
DEPTH mm/in 415 / 16.3 415 / 16.3
UNIT WEIGHT kg/lb 59 / 130.1 62 / 136.7
PIPE CONNECTION
TYPE FLARE VALVE FLARE VALVE
SIZE
LIQUID mm/in 6.35 / 1/4 6.35 / 1/4
GAS mm/in 12.70 / 1/2 15.88 / 5/8
REFRIGERANT CHARGE kg/lb 1.38 / 3.03 1.54 / 3.40
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
