AWM-G-2009 Engineering & Physical Data
General Data - Heat pump (R410A)
MODEL
INDOOR UNIT A5WM 301R
OUTDOOR UNIT A5LC 28CR
NOMINAL COOLING CAPACITY- 1Ø / <3Ø>
Btu/h 26000 / <26000>
W 7620 / <7620>
NOMINAL HEATING CAPACITY- 1Ø / <3Ø>
Btu/h 26000 / <26000>
W 7620 / <7620>
NOMINAL TOTAL INPUT POWER (COOLING)- 1Ø / <3Ø> W 2560 / <2631>
NOMINAL TOTAL INPUT POWER (HEATING)- 1Ø / <3Ø> W 2442 / <2294>
NOMINAL RUNNING CURRENT (COOLING)- 1Ø / <3Ø> A 12.2 / <4.6>
NOMINAL RUNNING CURRENT (HEATING)- 1Ø / <3Ø> A 11.6 / <4.2>
POWER SOURCE- 1Ø / <3Ø> V/Ph/Hz 220-240/ 1/ 50 / <380-415/ 3/ 50>
EER- 1Ø / <3Ø> W/W 2.98 / <2.90>
COP- 1Ø / <3Ø> W/W 3.12 / <3.32>
REFRIGERANT TYPE R410A
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE
INDOOR UNIT
CONTROL
AIR DISCHARGE
AUTO LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
OPERATION LCD REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 316 / 670
MEDIUM l/s / CFM 297 / 630
LOW l/s / CFM 236 / 500
SOUND PRESSURE LEVEL (H/M/L) dBA 49 / 47 / 45
UNIT DIMENSION
HEIGHT mm/in 360 / 14.2
WIDTH mm/in 1200 / 47.2
DEPTH mm/in 200 / 7.9
PACKING DIMENSION
HEIGHT mm/in 420 / 16.5
WIDTH mm/in 1267 / 49.9
DEPTH mm/in 260 / 10.2
UNIT WEIGHT kg/lb 17 / 37.5
CONDENSATE DRAIN SIZE mm/in 20 / 0.8
OUTDOOR UNIT
AIR FLOW l/s / CFM 632 / 1340
SOUND PRESSURE LEVEL dBA 54
UNIT DIMENSION
HEIGHT mm/in 756 / 29.8
WIDTH mm/in 855 / 33.7
DEPTH mm/in 328 / 12.9
PACKING DIMENSION
HEIGHT mm/in 810 / 31.9
WIDTH mm/in 990 / 39.0
DEPTH mm/in 415 / 16.3
UNIT WEIGHT kg/lb 68 / 149.9
PIPE CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm/in 9.52 / 3/8
GAS mm/in 15.88 / 5/8
REFRIGERANT CHARGE kg/lb 1.75 / 3.86
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
