53
Engineering & Physical Data AWM-G-2009
Component Data - Cooling Only (R22)
MODEL
INDOOR UNIT AWM 20G AWM 20G
OUTDOOR UNIT ALC 18C ALC 20C
INDOOR FAN
TYPE CROSS FLOW FAN CROSS FLOW FAN
QUANTITY 11
MATERIAL ACRYLO NITRILE STYRENE ACRYLO NITRILE STYRENE
DRIVE DIRECT DIRECT
DIAMETER mm/in 108 / 4.25 108 / 4.25
LENGTH mm/in 810 / 31.9 810 / 31.9
INDOOR FAN MOTOR
TYPE INDUCTION INDUCTION
QUANTITY 11
INDEX OF PROTECTION (IP) IP20 IP20
OUTDOOR FAN
TYPE PROPELLER PROPELLER
QUANTITY 11
MATERIAL
GLASS REINFORCED ACRYL
STYRENE RESIN
GLASS REINFORCED ACRYL
STYRENE RESIN
DRIVE DIRECT DIRECT
DIAMETER mm/in 457.2 / 18 457.2 / 18
OUTDOOR FAN
MOTOR
TYPE INDUCTION INDUCTION
QUANTITY 11
INDEX OF PROTECTION (IP) IP54 IP54
COMPRESSOR
TYPE ROTARY HERMETIC ROTARY HERMETIC
OIL TYPE ATMOS NM56M or SUNISO 4GDID ATMOS NM56M or SUNISO 4GDID
OIL AMOUNT cm
3
/ fl .oz. 600 / 21.1 1000 / 35.2
INDOOR COIL
TUBE
MATERIAL
SEAMLESS INNER GROOVE
COPPER
SEAMLESS INNER GROOVE
COPPER
DIAMETER mm/in 7.0 / 0.276 7.0 / 0.276
THICKNESS mm/in 0.28 / 0.011 0.28 / 0.011
FIN
MATERIAL
ALUMINIUM (HYDROPHILIC SLIT
FIN TYPE)
ALUMINIUM (HYDROPHILIC SLIT
FIN TYPE)
THICKNESS mm/in 0.11 / 0.0043 0.11 / 0.0043
FACE AREA m
2
/ft
2
0.269 / 2.900 0.269 / 2.900
ROW 22
FIN PER INCH 18 18
OUTDOOR COIL
TUBE
MATERIAL
SEAMLESS INNER GROOVE
COPPER
SEAMLESS INNER GROOVE
COPPER
DIAMETER mm/in 7.0 / 0.276 7.0 / 0.276
THICKNESS mm/in 0.28 / 0.011 0.28 / 0.011
FIN
MATERIAL ALUMINIUM (RAISE LANCE FIN) ALUMINIUM (RAISE LANCE FIN)
THICKNESS mm/in 0.11 / 0.0043 0.11 / 0.0043
FACE AREA m
2
/ft
2
0.52 / 5.59 0.52 / 5.59
ROW 12
FIN PER INCH 20 18
AIR QUALITY
FILTER
TYPE NANO FILTER NANO FILTER
QUANTITY pc 22
SIZE
LENGTH mm/in 351/13.8 351/13.8
WIDTH mm/in 386 / 15.2 386 / 15.2
THICKNESS mm/in 1.5 / 0.06 1.5 / 0.06
NEGATIVE IONIZER YES YES
CASING
INDOOR UNIT
MATERIAL HIGH IMPACT POLYSTYRENE HIGH IMPACT POLYSTYRENE
COLOUR LIGHT GREY LIGHT GREY
OUTDOOR UNIT
MATERIAL GALVANISED MILD STEEL GALVANISED MILD STEEL
COLOUR LIGHT GREY LIGHT GREY
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
